Model

YTO X904

Drive Type

4x4 ,4WD

Dimension(L*W*H)

4350mm*2300mm*2746mm

Wheelbase

2314mm

Min. Ground Clearance

440mm

Min. Operating Mass

3920kg

Tyre Size (F/R)

13.6-24/14.9-34

Wheel Track (F/R)

1562-2000/1520-2120mm

Gear Shift (F/R)

12/4

Speed Range (F/R)

1.65-27.17 & 4.28-12.85 km/h

Lifting Force (610mm)

>21.9KN

Lifting Force (Link Joint)

>25.6KN

Engine model

YTO LR4M5-23

Engine Type

4-cyliner,vertical,water cooler,4 stroke direct injection diesel engine

Engine Displacement

5.13L

Rated Power/Rotating Speed

66.2kW/2300rpm
