● Category:
● Brand Name: YTO
● Dimension (mm): 3300 x1210x2130
● Operating Weight (kg): 1250
● Origin: China
| Power(hp) | / | 50hp |
| Driving type | / | 4WD |
| External dimension (L × W × H) | mm | 3300 x1210x2130 |
| Commonly used wheel tread(front/rear) or gauge | mm | 1300/1460 |
| wheel tread(front/rear) or gauge | mm | 810/880-1440 |
| Minimum ground clearance and position | mm | 270 (bottom of traction plate) |
| Minimum weight | kg | 1250 |
| Standard Counterweight (Front/Rear) | kg | 48/60 |
| Number of gears (forward/backward) | / | 4F/2R |
| Maximum theoretical design speed | km/h | 34.62 |
| Number of engine cylinders | / | 4 |
| Engine nominal power | kW | 36.75 |
| Engine calibration speed | r/min | 2400 |
| Hydraulic suspension system type | / | Semi-split |
| Type of suspension | / | Three-point rear suspension |
| Hydraulic oil pump type | / | Gear pump |
| PTO shaft type | / | Rear semi-detached |
