● Category:
● Brand Name: YTO
● Dimension (mm): 5040×2380×3100
● Operating Weight (kg): 4950
● Origin: China
| Engine Type | YTO POWER | |
| Cylinders and displacement | 6/7.42L | |
| Cooling System and Fan Drive | Water Cooled | |
| Fuel Injection System & Control | Inline Mechanical Pump | |
| Aspiration | Naturally Aspirated | |
| Emission level | Stage II | |
| Bore & Stroke | mm | 108×135 |
| Rated power | KW | 95.6 |
| Rated Speed | rpm | 2300 |
| Preheater | yes | |
| Fuel tank capacity(underlying) | L | 230 |
| TRANSMISSION | ||
| Drive type | 4WD | |
| Clutch(dual-disc) | 12 inch LUK | |
| 12F/4R gear shift | yes | |
| 12F/4R Synchronizer shift | optional | |
| 24F/8R creeper gear shift(Min.0.3km/h) | optional | |
| Forward Speed range | km/h | 2.22-29.63 |
| Backward Speed range | km/h | 4.8-13.83 |
| REAR LINKAGE AND HYDRAULICS | ||
| 3 point hitch-rear Category | Category II | |
| Max. Lift Capacity @ 610 mm behind hitching point | KN | ≥33 |
| Hydraulic System type | Open Center | |
| Hydraulic pump flow | L/min | 45 |
| No. of SCV's (Selective Control Valve) | Std. 2 ( Opt. 3) | |
| Rated Traction | KN | 29 |
| Traction system | Trailed traction | |
| REAR POWER TAKE-OFF | ||
| PTO Power | KW | 72.15 |
| Number of splines | 6/21 spline | |
| PTO speed | 540/1000 | |
| DIMENSION | ||
| Dimension(Cabin) | mm | 5040×2380×3100 |
| Wheelbase | mm | 2688.5 |
| Ground clearance | mm | 470 |
| Min. turning radius | m | 7±0.6 |
| Wheel track (front) | mm | 1672-2003 |
| Wheel track (Rear) | mm | 1662-2262 |
| WEIGHT | ||
| Min. operation weight(ROPS&Canopy) | KG | 4950 |
| Min. operation weight(Cabin) | KG | 5200 |
| Front Ballast(Max. 10 piece) | 0×50kg | |
| Rear Ballast(Max.6 piece) | 0×50kg | |
| TIRE | ||
| Front tire | 14.9-26 | |
| Rear tire | 18.4-38 | |
| Front mudguard | optional | |
| Radial Tire | optional | |
| Cabin | yes |
