● Category:
● Brand Name: XGMA
● Dimension (mm): 5688×2270×3200
● Operating Weight (kg): 10600
● Origin: China
| Description | Unit | XG6102 | |||||
| Operating Weight | kg | 10600 | |||||
| Drum Weight | kg | 6000 | |||||
| Driving Wheel(D×W) | mm | Φ1550X2130 | |||||
| Travel Speed | km/h | 0~4.9 | |||||
| km/h | 0~7.3 | ||||||
| km/h | 0~10.4 | ||||||
| Max. Gradeability | % | 45% | |||||
| Vibration Frequency | Hz | 30 | |||||
| Amplitude (H/L) | mm | 1.7/0.85 | |||||
| Centrifugal Force(H/L) | KN | 225/112 | |||||
| Min. Turning Radius | mm | 6300 | |||||
| Engine | Brand | Cumins | |||||
| Model | 4BTA3.9 | ||||||
| Rated power | kW | 97 | |||||
| Rated speed | rpm | 2500 | |||||
| Overall Dimension(L×W×H) | mm | 5688×2270×3200 | |||||
