● Category:
● Brand Name: SINOTRUK
● Dimension (mm): 9450*2550*3450
● Operating Weight (kg): 18000
● Origin: China
| Overall dimensions | 9450*2550*3450mm |
| GVW | 18000kg |
| Chassis brand | SINOTRUK |
| Traction type | 4*2 |
| Up-parts Specification | ||
| Dustbin volume | 15cbm | |
| Material & thickness | Side | 4mm Q345 |
| Bottom | 5mm Q235A | |
| Type of Rear garbage filler(Rear Turnover device) | 1.Hanging trash bin | |
| 2.Swing arm | ||
| 3.Dustpan | ||
| Control system | Electrically Controlled Hydraulic + Manual Hydraulic | |
| Type of compactor | Fill, push and compression | |
| Garbage compact density | 0.9±0.05 T/cbm | |
| Sewage water tank | Rear | About 500L, on the bottom of rear filler |
| Front | About 230L, on the front of garbage van | |
| Max compact | ≥141 KN | |
| Max push | ≥189 KN | |
| Tailgate ascending Angle | ~95° | |
| Cycle of loading | ≤40s | |
| Cycle of discharge | ≤45s | |
| Hydraulic pressure system working pressure | 16 Mpa | |
| PLC | Importation PLC (Programmable controller) | |
| Gear pump | Made in China | |
| Multi-way valve | Air controlled, Made in China | |
| Hydraulic oil cylinder | Made in China | |
| Hydraulic rubber hose | Made in China | |
| Chassis Description | |||
| Cab | Sleeper cabin, 2 seat with one bunk with A/C | ||
| all-steel forward control | 55 hydraulically tiltable to the front | ||
| adjustable air driver's seat | adjustable rigid co-driver's seat | ||
| with ventilation system | exterior sun visor | ||
| stereo radio/usb interface | safety belts | ||
| adjustable steering wheel | air horn | ||
| with 4-point support fully floating suspension and shock absorbersbb | |||
| 2-arm windscreen wiper system with three speeds | |||
| Engine | Brand | SINOTRUK WD615.62 | |
| Model | Diesel: 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-char in and inter-cooling | ||
| Emission standard | EURO 2 | ||
| Displacement (L) | 9.726 | ||
| Horse power | 266HP/196kW | ||
| No of cylinder | 6 | ||
| Maximum torque | 1100N.m @ 1100~1600rpm | ||
