● Category:
● Brand Name: SINOTRUK
● Dimension (mm): 9580*2500*3550
● Operating Weight (kg): 31000
● Origin: China
| Announcement model: | ZZ3317V326GF1 | Drive form: | 8X4 |
| Wheelbase: | 1950+3225+1350mm | engine: | Sinotruk MC11.44-60 |
| Gearbox: | SINOTRUK HW25712XSL | Rear axle speed ratio: | 5.26 |
| Body length: | 9.58 meters | Body width: | 2.55 meters |
| Body height: | 3.55 meters | Front track: | 2022/2022mm |
| Rear wheelbase: | 1860/1860mm | Vehicle weight: | 15.5 tons |
| Rated load: | 15.37 tons | Total mass: | 31 tons |
| Tonnage level: | Heavy Truck | Approach angle: | 17 degrees |
| Departure angle: | 21 degrees | Origin: | Shandong Jinan |
| Market segments: | Urban construction debris | Fuel type: | diesel fuel |
| Engine parameters | |||
| engine model: | Sinotruk MC11.44-60 | Engine brand: | SINOTRUK |
| Number of cylinders: | 6 cylinder | Fuel type: | diesel fuel |
| Displacement: | 10.518L | Emission Standards: | National VI |
| Maximum horsepower: | 440 HP | Maximum output power: | 324kW |
| Maximum torque: | 2100Nm | Maximum torque speed: | 1000-1400rpm |
| Rated speed: | 1900rpm | Engine form: | High voltage common rail+EGR+SCR |
| Carton parameters | |||
| Carton length: | 6.5 meters | Cargo box width: | 2.35 meters |
| Cargo box height: | 1.5 m | Container form: | Self-unloading |
| Cab parameters | |||
| Driver's seat form: | Airbag shock-absorbing seat | ||
| Gearbox parameters | |||
| Gearbox model: | SINOTRUK HW25712XSL | Gearbox brand: | SINOTRUK |
| Forward gear: | 12 gears | Number of fallen boxes: | 2 |
| tank | |||
| Fuel tank material: | Aluminum alloy | Fuel tank capacity: | 400L |
| Chassis parameters | |||
| Allowable load on front axle: | 6500/7000kg | Allowable load on rear axle: | 17500(two-axle group)kg |
| Number of spring leaves: | 4/4/12,11/11/12 | ||
| tire | |||
| Tire specifications: | 12.00R20 | Number of tires: | 12 |
