● Category:
● Brand Name: SINOMACH
● Dimension (mm): 5835*2240*2313
● Operating Weight (kg): 8000
● Origin: China
| Dmension | Length(with bucket on ground) (mm) | 5835 |
| Width (mm) | 2240 | |
| Load Bucket width (mm) | 2313 | |
| Height(To the top of the cab) (mm) | 2720 | |
| Height(To the top of the digging pole) (mm) | 3548 | |
| Wheel base (mm) | 2155.5 | |
| Min. ground clearance (mm) | 275 | |
| Loading Performance | Rated load (Kg) | 1700 |
| Operating weight | 8000 | |
| Rated bucket capacity (m3) | 1.0 | |
| Max. dump clearance (mm) | 2714 | |
| Dump reach (mm) | 845 | |
| Max lifting capability (Kg) | 3400 | |
| Max. load breakout force (kN) | >60 | |
| Digging Performance | Rated digging bucket capacity (m3) | 0.2 |
| Max. digging depth (mm) | 4405 | |
| Max. digging radius (mm) | 5390 | |
| Max. dumping height (mm) | 3510 | |
| Max. digging force (kN) | >56.1±10% | |
| Engine | Model | WD DEUTZ WP4G95E221 /4BTA3.9-C110 |
| Type | Direct injection. Turbocharged. Water cooling | |
| Rated output | 70 (kW)@2200rpm /82 (kW)@2200rpm | |
| Displaement | 4.5(L) /3.9(L) | |
| Travelling performance | Gears | F4R4 |
| Speed(F/R) | 6/6,9.6/9.6,20.5/20.5,38/38 | |
| Max. drawing force | 70kN |
