ated Load(kg)

3000

Operating Weight(kg)

9700

Bucket Capacity(m³)

1.53-2.50

Wheelbase(mm)

2630

Overall Dimensions (mm)(L*W*H)

7162*2354*3051

Turning Radius(mm)

5869

Max. Breakout Force(KN)

120

Max. Tractive Force(KN)

97

Transmission

model

TR100

Transmission type

fixed shaft power shift transmission

gear shift

F4/R2

torque converter type

unipolar three element centripetal

Drive axle

Main drive type

single screw speed reducer

wheel reduction type

primary planetary reducer

swing angle(°)

12

Diesel engine

model

WP6G125E333

rated power(KW)

92

rated speed(r/min)

2000

displacement(L)

6.7

Hydraulic system

time(s)

4.6

Hydraulic cycle time (Total)(s)

8.2

working pressure(MPa)

16.5

Brake system

Service Brake

Air assisted oil disc type four wheel brake

Parking Brake

internal expansion

Tire

Model

17.5-25

type

low pressure wide base diagonal tire

layer

12

pattern type

L3
