● Category:
● Brand Name: SANY
● Dimension (mm): 6890×2400×3070
● Operating Weight (kg): 10200
● Origin: China
| rated loading | 3000kg | |
| overall weight | 10200kg | |
| rated bucket capacity | 1.8m3 | |
| maximum tractive force | 97KN | |
| maximum breakout force | 127KN | |
| maximum grade ability | 30ºC | |
| maximum dump height | 3100mm | |
| maximum dump reach | 1006mm | |
| overall dimension (L×W×H) | 6890×2400×3070mm | |
| 7820*2560*3280mm | ||
| minimum turning radius | 5250mm | |
| type | ,, lnline water cooled, four stroke | |
| -×No. of cylinder-bore/stroke | 6-108×125mm | |
| rated power | 92kw | |
| maximum torque | 515N.m | |
| min fuel-consume ratio | ≤210g/kw.h | |
| torque converter | YJ315-x | |
| gearbox mode | Power shift normally engaged straight gear | |
| gear shift | , 4forward shift 2 reverse shift | |
| maximum speed | 40km/h | |
