Capacit

Max. lifting capacity

50t

Dimensions

Overall lengthxwidthxheight

13750x2750x3800mm

Axle distance-1,2

1450mm

Axle distance-2,3

4000mm

Axle distance-3,4

1350mm

Weight

Overall weight

42t

Front axle load

16t

Rear axle load

26t

Engine

Rated power

250KW/2100rpm

Trated torque

1425N.m/1200-1400rpm

Travelling

Max. traveling speed

85km/h

Min.turning radius

12m

Min.turning radius of boom head

14.5m

Min. ground clearance

295mm

Approach angle

18°

Departure angle

12°

Max. gradeability

40%

Fuel consumption per 100km

less than 45L
