LUTONG

● Category:

● Brand Name: LUTONG

● Dimension (mm): 2900x1400x2520

● Operating Weight (kg): 4000

● Origin: China

Specifications
Model LTC204
Operating mass 4000kg
Static linear load Front 150/ Rear 150N/cm
Vibration amplitude Front 0.5/ Rear 0.5mm
Centrifugal force 2x30Kn
Vibration frequency 50Hz
Max Travel speed 0-12Km/h
Ground clearance 320mm
Electrical voltage 12v
Grade ability 25%
Overall dimension (LxWxH) 2900x1400x2520mm
Drum diameter 700mm
Drum width 1300mm
Wheel base 2010mm
Diesel engine power 26.5Kw
Diesel engine model ZN390B
Water tank capacity 200L
Ship 2units/20GP 4units/40HQ
