● Category:
● Brand Name: LUTONG
● Dimension (mm): 4740×2170×2990
● Operating Weight (kg): 4910
● Origin: China
| Tractor Model | LT1404B |
| Drive Type | 4×4 |
| Overall Dimension with driver's cab L×W×H(mm) | 4740×2170×2990 |
| Wheel base (mm) | 2490 |
| Front wheel tread (mm) | 1760 |
| Rear wheel tread (mm) | 1620 |
| Min. ground clearance (mm) | 475 |
| Min. operating weight with driver's cab (KG) | 4910 |
| Gearbox gears number | 16F+8R |
| Forward Speed (Kw/h) | 0.44-33.34 |
| Reverse Speed (Kw/h) | 0.59-10.31 |
| Engine Brand | YTO POWER |
| No.of cylinder | 6 |
| Engine Rated power (Kw) | 103 |
| Engine Rated speed(r/min) | 2200 |
| Front tires spec. | 13.6-24 |
| Rear tires spec. | 16.9-34 |
| Max. traction force (KN) | 42.2 |
| Max. lifting force (KN) | 24.8 |
| PTO Power (Kw) | 87.6 |
| PTO Type | Rear-mounted, Independent type |
| PTO Speed (r/min) | 760/850 or 540/1000 |
| PTO Shaft Size | φ38mm×8 splines or 6 splines |
| Steering type | Full hydraulic front wheels steering |
| Control type of ploughing depth | Height control & Flotation control |
| Front/Rear Iron Ballast (KG) | 400/320 |
| Fuel Tank Capacity (L) | 200 |
