Tractor Model

LT1304

Drive Type

4×4

Overall Dimension L×W×H(mm)

5050×2370×3000

Wheel base(mm)

2688.5

Front wheel tread(mm)

1822-2153

Rear wheel tread(mm)

1662-2262

Min. ground clearance(mm)

470

Min.  steering radius

7

Min. operating weight (KG)

4810

Gearbox gears number

12/4

Speed

Forward(Kw/h)

29.63-2.19

Reverse(Kw/h)

13.83-4.72

Engine

Model

LR6A3ZU22/0956E

Rated power (Kw)

95.6

Type

6 cylinders, in line, water cooling, 4 strokes, direct injection, natural aspiration

Rated speed (r/min)

2200

Tires spec.

Front tires

14.9-26

Rear tires

18.4-38

Max. lifting force( KN )

≥28

Front / rear Ballast (KG)

600/400

PTO

Type

Rear-mounted, Independent type

Speed (r/min)

540/720

Power(Kw)

81.7

Max. traction force (KN)

32
