● Category:
● Brand Name: LONKING
● Dimension (mm): 4300x1160x2150
● Operating Weight (kg): 2000
● Origin: China
| Performance | Model | HR180 |
| Rated loading | 800kg | |
| Operation weight | 2000kg | |
| Max. Shovel width | 1180mm | |
| Bucket capacity | 0.3cbm | |
| Max. grade ability | 30° | |
| Min. ground clearance | 200mm | |
| Wheelbase | 1540mm | |
| Steering angle | 49° | |
| Max. dump height | 2617mm | |
| Load over height | 2634mm | |
| Hinge pin height | 2900mm | |
| Dinging depth | 94mm | |
| Dump distance | 920mm | |
| Overall dimension (L*W*H) | 4300x1160x2150mm | |
| Min. turning radius over shovel | 2691mm | |
| Min. turning radius over tyres | 2257mm | |
| Track base | 872mm | |
| Dumping angle | 45° | |
| Function of leveling automatic | Yes | |
| Engine | Brand | Kubota |
| Model | HKBXL01.5BCB | |
| Type | Vertical, in-line, water cooling, 3-cylinder | |
| Rated power | 18.7KW | |
| Transmission system | Type | Hydrostatic |
| System pump type | Variable displacement piston | |
| Drive type | Independent wheel motors | |
| Classic angle oscillation | 7.5 each way | |
| Max. speed | 20km/h | |
| Loader hydraulic | Pump type | Gear |
| Pump maximum flow | 42L/min | |
| Pump maximum pressure | 200bar | |
| Electric output | System Voltage | 12V |
| Alternator output | 65Ah | |
| Battery capacity | 60Ah | |
| Tyre | Tyre model | 10.0/75-15.3 |
| Optional Tyre | 31x15.5x15 | |
| Filling capacity | Hydraulic and transmission system | 40L |
| Fuel tank | 45L | |
| Engine oil sump | 7.1L |
