Operating Mass

11350 kg

Mass On Vibrating Drum

6350 kg

Mass On Drive Axle

5000 kg

Front Drum Static Linear Load

292 N/cm

Emission Regulation

Stage II

Rated Power

93 kW (126 hp) @ 2200 rpm

Vibration Frequency

30/33 Hz

Nominal Amplitude

2.0/1.1 mm

Centrifugal Force

300/190 kN

Drum Diameter

1555 mm

1st Maximum Speed, fwd

6 km/h

2nd Maximum Speed, fwd

10.5 km/h

Theoretical Gradeability

45%

Min. GroundClearance

470 mm

Wheelbase

2980 mm

Min. Outside Turning Radius

6500 mm

Overall Length

6000 mm

Overall Width

2280 mm

Overall Height

3180 mm
