Operating Weight

Kg

53000

Engine Model

Cum mins QSM11

Rated Power

Kw

298KW/2000rpm

Bucket Capacity

m³

3

Max Digging Force

Kn

325

Swing Speed

rpm

0-11

Traveling Speed

km/h

2.4-4.4

Gradeability

°

35°

System Working Pressure

Mpa

35

Boom Length

mm

6500

Arm length

mm

2550

Operating Range

Max. Digging Radius

mm

10726

Max. Digging Depth

mm

5756

Max. Digging Height

mm

11142

Max. Dumping Height

mm

7779

Max. vertical digging depth

mm

5064

Overall Dimensions

Overall Length

mm

11690

Overall Width

mm

3360

Overall Height

mm

3810

Mini.Ground Clearance

mm

602

Track Width

mm

600

Axle base(Track length on ground)

mm

4021

Track Gauge

mm

2760

Swing radius at tail

mm

3760
