● Category:
● Brand Name: HELI
● Dimension (mm): 5490*2164*2550
● Operating Weight (kg): 13120
● Origin: China
| General | 1 | Model | CPCD-120 | ||||||
| 2 | Rated Load Capacity | kg | 12000 | ||||||
| 3 | Loader Center | mm | 600 | ||||||
| Dimensions | 4 | Lifting Height | mm | 3000 | |||||
| 5 | Free lifting Height | mm | 180 | ||||||
| 6 | Fork Size | LxWxT | mm | 1220×175×80 | |||||
| 7 | Mast Tilting Angle | F/R | 6/12 | ||||||
| 8 | Length(without fork) | mm | 4270 | ||||||
| 9 | Overall Width | mm | 2164 | ||||||
| 10 | Mast Hight After Mast Fall | mm | 2700 | ||||||
| 11 | Lift Height | mm | 4400 | ||||||
| 12 | Overhead Guard Height | mm | 2550 | ||||||
| 13 | Turning Radius | mm | 4110 | ||||||
| 14 | Front /back Overhang | mm | 700/755 | ||||||
| 15 | Min.Right Angle Channel Width | mm | 3740 | ||||||
| 16 | Wheelbase | mm | 2800 | ||||||
| 17 | Track | Front | mm | 1600 | |||||
| 18 | Rear | mm | 1720 | ||||||
| 19 | Ground Clearance | Mast | mm | 240 | |||||
| 20 | Car Center | mm | 290 | ||||||
| Tire | 21 | Front Tire | 900-20-14 | ||||||
| 22 | Rear Tire | 900-20-14 | |||||||
| Performance | 23 | Speed | Travel | Full Load | km/h | 24 | |||
| 24 | No load | km/h | 26 | ||||||
| 25 | Lifting | Full Load | mm/s | 330 | |||||
| 26 | No load | mm/s | 350 | ||||||
| 27 | Lowering | Full Load | mm/s | 380 | |||||
| 28 | No load | mm/s | 350 | ||||||
| 29 | Max.Drawbar Pull | Full/No Load | kg | 62000/49500 | |||||
| 30 | Max.Gradeability | Full/No Load | % | 15/20 | |||||
| Weight | 31 | Total Weight | kg | 13120 | |||||
| Pover&Transmission | 32 | Battery | Voltage/Capacity | V/AH | 24/80 | ||||
| 33 | Engine | Model | Xinchai CA4DF3 | ||||||
| 34 | Rated Pover/Speed | Kw/rpm | 85/2200 | ||||||
| 35 | Max.Torque/Speed | N.m/rpm | 460/1400-1500 | ||||||
| 36 | Work Pressure | Mpa | 20 | ||||||
| 37 | Fuel Tank Capacity | L | 60 | ||||||
