● Category:
● Brand Name: CHANGLIN
● Dimension (mm): 5850×2250×3080
● Operating Weight (kg): 12000
● Origin: China
| Operating weight (kg) | 12000 |
| Vibratory drum diameter (mm) | 1450 |
| Compaction width (mm) | 2100 |
| Static line pressure (N/cm) | 317 |
| Min. ground clearance (mm) | 420 |
| Wheel base (mm) | 3000 |
| Min. turning radius (mm) | 6200 |
| Gradeability | 45% |
| Vibratory amplitude(mm) | 1.9/0.9 |
| Vibratory frequency (Hz) | 30/35 |
| Centrifugal force (kN) | 280/180 |
| Travelling speed | |
| (Forward)(km/h) | 0-5.5/0-10 |
| (Reverse) (km/h) | 0-5.5/0-10 |
| Tyre model | 20.5-25-16PR |
| Engine model | WP4G110E221 |
| Rated power | 82kw@2200rpm |
| Dimension (mm) | 5850×2250×3080 |
