● Category:
● Brand Name: BEIBEN
● Dimension (mm): 9800×2485×3250
● Operating Weight (kg): 12450
● Origin: China
| Vehicle Main Dimensions | Overall dimensions (L x W x H)mm |
9800×2485×3250 |
| Wheel base (mm) | 4350+1450 | |
| Wheel track (front/rear) (mm) | 1960/1860,1860 | |
| Weight in KGS | Tare Weight | 12450 |
| payload | 12100 | |
| Front axles loading capacity | 7000 | |
| Rear axles loading capacity | 18000 of 2 axle combined | |
| Max. driving speed(km/h) | ||
| Engine | Brand | Weichai Engine |
| Model | WP10.320E33 | |
| Type | 4-stroke direct injection,6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Engine dispacement(L) Horse Power(HP) |
Engine displacement: 9.726L 320HP, other engine power are optional | |
| Emission standard | Euro 2 | |
| Gearbox | Manual operation, FAST brand, 9 speed forward and 1 reverse gear | |
| Steering | Hydraulic steering with power assistance | |
| Clutch | Reinforced diaphragm clutch | |
| Tire | 12.00-20 tyre 10+1 pcs including one spare tire.Off-road tire is optional | |
| Tank specification | 20000 liters Tank materia:Carbon steel Q235.(Carbon steel,Stainless steel or Aluminum alloy are optional) Equipped with front(rear,side)sprinkler Equipped with high powerful water pump Equipped with water monitor & Water Gun & Water cannon Equipped with fire valve,water valve,and filter gauze | |
