● Category:
● Brand Name: BEIBEN
● Dimension (mm): 8935×2500×3890
● Operating Weight (kg): 14000
● Origin: China
| Catagory | Item | Unit | Parameter |
| Overall Parameter | Model | G08K | |
| Curb weight | kg | 14000 | |
| Max.total weight | kg | 25000 | |
| Outline dimension | (L×W×H) mm | 8935×2500×3890 | |
| Chassis | Chassis brand | ||
| Chassis model | ZZ1257N3641W | ||
| Steering position | LHD | ||
| Driving type | 6×4 | ||
| Wheel base | mm | 3625+1350 | |
| Tire | 10.00R20 | ||
| Power take-off | Flywheel | ||
| Engine | Model | WD615.69 | |
| Max.power | kW | 247 | |
| Displacement | L | 9.726 | |
| Drum system | Geometric volume | m³ | 13.6 |
| Agitating volume | m³ | 8 | |
| Max.diameter of drum | mm | 2280 | |
| Mixing drum length | mm | 4795 | |
| Slanting angle | ° | 15 | |
| Rotating speed | r/min | 0~14 | |
| Feeding speed | m³/min | ≥3 | |
| Discharge speed | m³/min | ≥2 | |
| Discharge residual rate | % | < 0.4 | |
| Slump scope | mm | 50~210 |
