Product classification
Product classification
● Category:
● Brand Name: Dump Truck
● Dimension (mm): 5998x2196x2410
● Operating Weight (kg): 5180
● Origin: China
TRUCK SPECS |
Overall dimension: | 5998x2196x2410mm | |
| Cabin | Cabin size: | standard cabin(2 seats) | |
| Seats and sleeper Bed: | 2 seats/ | ||
| Air conditioner: | standard | ||
| Engine | Horsepower(hp): | 140 | |
| Tech: | FAW/ CUMMINS tech | ||
| Engine Type: | 4-cylinder in line, 4-stroke, water-cooled,turbocharged, intercooled | ||
| Emission Standard: | EUR 2 | ||
| Fuel Type: | Diesel | ||
| Engine Capacity(ml): | 3826 | ||
| Gear Box/Transmission | 5 /6 speeds and 1 reverse speed | ||
| Clutch | Φ350 | ||
| Axles | Front Axles: | 3.5T | |
| Driving Axles: | 7T | ||
| Tyre: | 7.00R20,6 Radial tires with one spare tire | ||
| Max speed: | 75km/h | ||
| Tare weight(MT): | 8MT | ||
BODY SPECS |
Body Dimensions (LengthXWidthXHeight): |
3800X2300X800mm 4000x2300x800mm | |
| Material: | Q235 | ||
| Body steel (mm): | floor 4mm,side 3mm | ||
| Cpacibility(M3): | 6CBM | ||
| Lift System: | hydraulic system with power assistance | ||
| Wheel base: | 3250/3850mm(12.55x4.43ft) | ||
| Track Width(front/rear): | 2041/1830mm(7.91x6ft) | ||
| Overhang(front/rear): | 1500/1870mm(7.55x6.14ft) | ||
| Approach/Departure Angle: | 19°/23° | ||
