Product classification
Product classification
● Category:
● Brand Name: Dump Truck
● Dimension (mm): 8265*2496*3490
● Operating Weight (kg): 12270
● Origin: China
| Truck Brand | HOWO | |
| Dimensions (L*W*H) | 8265mm*2496mm*3490mm | |
| Cargo body size (L*W*H) | 5600mm*2300mm*1500mm | |
| Cargo thickness (mm) | Bottom: 8mm, Side: 6mm | |
| Lift type of Carriage | Middle lifting system | |
| Approaching angle/Departure angle (°) | 20/26 | |
| Overhang(front/rear) (mm) | 1540/1750 | |
| Wheel base (mm) | 3625+1350 | |
| Curb weight (kg) | 12270 | |
| Loading Weight (kg) | 30,000 | |
| Fuel tanker capacity (L) | 300 | |
| Engine Model |
Fuel type | Diesel |
| Horse Power, max (kw/rpm) | 371HP | |
| Emission | EURO 2 | |
| Model | WD615.47, water-cooled,four strokes ,6 cylinders in line with water cooling , electric injection | |
| Transmission | Model | HW19710, 10 forwards and 2 reverse |
| Brake system | Service brake | Dual circuit compressed air brake |
| Parking brake | spring energy, compressed air operating on rear wheels | |
| Auxiliary brake | Engine exhaust brake | |
| Steering system | Model | ZF8118 hydraulic steering with power assistance |
| Front axle | HF9, Steering with double T-cross section beam | |
| Rear axle | HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels | |
| Tyre | 12.00 R20 radial tires, 10+1 pcs | |
| Electrical system | Battery | 2X12V/ 165Ah |
| Alternator | 28V-1500kw | |
| Starter | 7.5Kw/24V | |
