Product classification
Product classification
● Category:
● Brand Name: Fuel Tank Truck
● Dimension (mm): 5990x2050x2500
● Operating Weight (kg): 3760
● Origin: China
| Tank volume | 6.2 Cube | On the household tonnage | 3405(kg) |
| outline dimension | 5.99x2.05x2.5(m) | gross mass | 7360(kg) |
| Tank size | 4×1.7×1. I(m) | unloaded weight | 3760(kg) |
| Pipe body thickness | 4.2imm) | Tank material | carbon steel |
| Chassis technical parameters | |||
| brand | Liberation tiger V | Chassis model | CA1077P40K50L1 |
| number of axles | 2 | wheel base | 3300imm) |
| engine | Weichai has 110 horsepower | gear-box | 5 File |
| tyre size | 7.00 steel wire tire | Front and rear bridge | After 130 bridge |
| Fuel types | diesel oil | Environmental standards | country V |
| ABS | standard configuration | brake assembly | Broken gas brake |
| Front brake | disk | Rear brake | drum-type |
| maximum speed | 80Km/h | Approximate number | 3 |
