● Category:
● Brand Name: Fuel Tank Truck
● Dimension (mm): 11925X2500X3500
● Operating Weight (kg): 19700
● Origin: China
| Condition | New condition/RHD hand drive or left hand drive/8x4 | ||
| Chassis | Brand | foton | |
| Curb weight(kg) | 10700 kg | ||
| Wheelbase(mm) | 1860+4700+1350 mm | ||
| Dimensions(mm) | 11925X2500X3500 mm | ||
| Front/Rear Axle loading(kg) | 6500/7000/18500 kg | ||
| Wheel track (front/rear) (mm) | 1960/1955 mm | ||
| Front/Rear overhang(mm) | 1555/2410 mm | ||
| Approach/Departure angle(°) | 19/19 | ||
| Max. driving speed(km/h) | 95 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
Brakes |
Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10 pcs with one spare tire | |
| Specifications | 12R22.5 | ||
| Transmission | Manual type, 6 Forwards and 1 reverse | ||
| Cab | It can accommodate three people. With Air Conditioner | ||
Engine |
Brand | Cummins | |
| Model | ISD245 50 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 6700 ml | ||
| Power(kw) | 271kw | ||
| Horsepower(HP) | 371HP | ||
| Cylinder number | 4 | ||
| Emission standard | Euro 5 | ||
| Fuel Tank | |||
| Fuel tank | Capacity(cbm/liters) | 30cbm/30,000 liters | |
| Tank material | Tank material:Q235 high tensile strength steel. | ||
| Thickness(mm) | 6mm of tank and 7mm of end plate | ||
| Compartment No. | 2 | ||
| Baffle | 1 No,4 mm carbon steel | ||
| Manhole cover | 2 manhole covers, ∮500mm 2 sets with 2 breather valves | ||
| Bottom Valve | 2 sets of API Pneumatic Bottom Valves | ||
| Discharging valve | 2 set ∮ discharging valves | ||
| Handrail | Two sides | ||
| Ladder | At rear of tank | ||
| Painting | Color and design as customer's requirement | ||
