● Category:
● Brand Name: Truck Mounted Crane
● Dimension (mm): 6865*2260*3100
● Operating Weight (kg): 4500
● Origin: China
| G.V.W. | 7800kg | |
| Work line voltage | 66 KV | |
Bucket | ||
| Max. work height | 15.3m | |
| Max. bucket floor height | 13.6m | |
| Max. work radius | 9.3m | |
| Bucket load | 200kg | |
Boom | ||
| Type | One articulated, two sections telescopic | |
| Rotation angle | 360° | |
Outrigger | ||
| Type | H | |
| Adjustment | Adjusted separately | |
Chassis | ||
| Model | MAXUS SH1083ZFDDMS | |
| Cabin | Double, 4-doors | |
| Seat capacity | 6 persons | |
| Wheelbase | 3808mm | |
| Steering | Power steering, L.H.D. | |
| Engine | ||
| Model | D30TCIF1 | |
| Engine power | 125 kW | |
| Discharge Standard | euro 6 | |
| Fuel | Diesel | |
