Model

SLM3500

Dimension (L×W×H)

7117×2500×3331 mm

Weight (approx.)

8600 kg

Performance

Mixing Drum Capacity

Drum capacity 5.3m³,Concrete output: 3.5 m³ per batch

Mixing Speed

0-20rpm in full, infinitely variable speed change

Loading Speed

3 shovels/min, 650L/Shovel

Water Pumping Capacity

1.5 min/batch, 40 t/hour

Traveling Speed

Low Speed: 0-10km/hour / High Speed: 0-20km/hour

Drum Rotation

Horizontal rotation 270°

Transmission Type

4 wheel drive and 4 wheel steering

Electrical System

24V

Water Tank Capacity

2x350L

Diesel Tank Capacity

150L

Hydraulic Oil Tank Capacity

125L

Engine

Model

YC4A125Z

Manufacturer

YUCHAI

Rated Power

92 KW

Displacement

4.84 L
