Driving form:

4X2

Wheel base:

2950mm

Case length class:

3.8 meters

Engine:

E60 QuanChai Q23-115

Gearbox:

Wan Liyang WLY5GT32

Rear axle speed ratio:

4.875

Length of body:

5.16 meters

Width of body:

2 meters

Body height:

2.83 meters

Before the wheel track:

1521mm

After the wheel track:

1494mm

Vehicle weight:

2.805 tons

Rated load:

1.495 tons

Total quality:

4.495 tons

Maximum speed:

103KM/h

Class of tonnage:

Light trucks

Approach Angle:

24 degrees

Angle of departure:

10 degrees

Remark:

Power supply: 12V, air conditioning, dovetail beam in frame form

Front/rear overhang:

1.04/1.647th of a metre

Version:

Can sharpen version

Engine Type:

E60 QuanChai Q23-115

Commonly known as engine:

QuanChai 487

Cylinder number:

4

Type of fuel:

diesel

Cylinder arrangement form:

inline

Displacement:

2.3 L

Emission standard:

The six

Maximum output power:

85kw

Maximum horsepower:

115 horsepower

Maximum torque:

320 n. m

Maximum torque speed:

2000RPM

Rated speed:

3000RPM

Type of engine:

Inline four cylinder, water cooled, four stroke, supercharged medium cooled, high pressure common rail

Form of container:

van

Length of container:

3.8 meters

Container width:

1.88 meters

Height of container:

1.9 meters

Width of cab:

1730mm

Number of permitted passengers:

Three people

Number of rows:

Single row

Gear shifting mode:

manual

Forward gear:

5 block

Reverse gear number:

1

Fuel tank material:

steel

Tank capacity:

55L

Allowable load of front axle:

1800KG

Frame size:

190 * 55 * 5 mm

Allowable load of rear axle:

2695KG

Ratio:

4.875

Number of spring pieces:

6/6 + 5

Specification of tire:

6.50 R16 10 pr

Tyre number:

six
