Product classification
Product classification
● Category:
● Brand Name: Semi-trailer
● Dimension (mm): 13000x3000x3500
● Operating Weight (kg): 8600
● Origin: China
| Dimension | 13.00mx3.00mx3.50m (0utside) |
| Payload(kg) | 60000kg |
| Kerb Mass(kg) | 8600kg |
| GVWR(kg) | 38000kg |
| Main beam | Heavy duty and extra durability designed l beam, Opting for high tensilesteel 0345B,welded by automatic Submerged-Arc processes |
| Frame Beam | Top Flange 14mm,width 140mm, Middle Flange 8mm; Bottom Flange16mm,width 140mm, main beam height 500mm |
| Axle | 3 axles, 13Ton Fuwa brand 16ton brake pads |
| Landing Gear | Fuwa 28T lifting capacity with two speed |
| King Pin | 2.00 inch bolt-in king pin Brand JosT |
| Suspension | Mechanical suspension reinforced type |
| Leaf Spring | 90mm(w)*13mm(T)*10 Layer |
| Pneumatic Braking System | Dual line pneumatic brake system,T30 air chamber ,40L air tanksEmergency relay valve |
| Rim | 9.0-20*12 pCS |
| Tire | 12R22.5*12 pCS |
| Accessories | One standard tool box |
| Spare tire rack | one |
| Electrical system | 24 volt electrical system.7 pin electrical connector. Parking stop, reversenumber plate and indicator lights.rear lights conform to European standard, rear front and side reflectors |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosiveprime, 2 coats of final paint |
| Shipping Terms | By Bulk CargO/RORO OR 45ft HQ container |
