Product classification
Product classification
● Category:
● Brand Name: Semi-trailer
● Dimension (mm): 19800X 3300X 1750
● Operating Weight (kg): 12000
● Origin: China
| Name: | Lowbed semi trailer | Tare Weight: | Around 12T |
| Spec.: | LXY9700TDP Size: 19800X 3300X 1750 |
Axle: | Longer axle, Fuwa brand, 4pcs |
| Main beam: | Height: 500mm, Top flange: 16mm, under flange: 20mm, middle flange: 14mm, material: Q550D |
Leaf spring: | Standard 10pcs,, Taiyue brand |
| Side beam: | Height: 250mm, Top flange: 8mm, under flange: 8mm, middle flange : 8mm |
Brake chamber: | 8 double, Fuwa brand |
| Cross beam: | Bending steel, 5mm match with 4mm | Rim: | 9.0#(thicken)*18 pcs |
| King pin: | 90# & 50# | Tyre: | 12R22.5*18 pcs Triangle brand |
| Suspension: | Thickening suspension, 60 pin | Air tanker: | 3 pcs |
| Floor: | Diamond plate, both sides plate: 4mm, middle plate: 4mm | Emergency valve: | WABOCO |
| Landing gear | 28T, Fuwa brand, | Gas circuit: | &12 red yellow nylon tube |
| Draw plate: | Thickness:14mm, dovetailed type | Tool box: | 2pcs |
| Tyre carrier: | 2 pcs | Wire tightener: | 24 pcs |
| Leg crank: | 1 pair | Shaft head wrench |
1 pc |
| Electric system: | Voltage: 24V, socket: in line with the Chinese national standard seven-core socket, LED lights, wiring harness: 7-core waterproof wiring harness. | ||
| Payload: | 60T | Paint: | One anti-rust paint, one polyurethane, wax spray |
