Size

13000x2550x2700mm (Optional)

Tyre specifications

12R22.5/11R22.5/13R22.5/11.00R20/12.00R20(specificationcan be Optional)

Axles

13T/16T,FUWA/BPW/YAHUA / brand or optional

Suspension

Mechanical suspension(German Type or America Type) or Air suspension

Payload

30T-80T

Rim

8.00-20/8.5-20/8.8-20   (Patent of electrophoretic paint)

Spring leaf

8/8/8, 10/10/10, 12/12/12 pieces

King pin

JOST brand 2.0 or 3.5 inch bolts type or Welding type

Support leg

JOST/FUWA/YAHUA brand or China brand 28ton(two speed or single speed )

Main Beam

Height: 450mm-520mm, upper plate thickness is 14mm-25mm, middle plate thickness is 8mm-12mm, down plate thickness is 16mm-25mm; Material is Q345 manganese steel  .

Usage

For bulk cargo/container transportation

Brake System

Double pipe line air brake, front two axle is 30 air chamber, rear axle is 30/30 air chamber.

Twist Locks

Four ,Eight or Twelve pieces(lifting type or Twist Screw Type) Optional locks for loading containers

Electrical system

24V,7 pin socket,One set 7-core standard Cable

Light

Tail lamp with turn signal, brake light & reflector,

side lamp etc

Tool box

1 set

Spare tire carrier

2 sets

Color and Logo

Depends on the buyer's requirement.
