● Category:
● Brand Name: Semi-trailer
● Dimension (mm): 11,000x2,550x3,800
● Operating Weight (kg): 7500
● Origin: China
| Overall dimension(mm) | 11,000x2,550x3,800 or customized |
| Rated Payload(kg) | 70,000kg or customized |
| Box Dimensions (mm) | 10,500x2,350x1,850 or customized |
| Bucket Shape | U shape or Rectangle shape |
| Main beam (mm) | 1.Main bracket 500mm height, Submerged arc welding, Q345B or T700L strong metal frame 2. HARDOX 450 Metal is optional |
| Flange and web(mm) | 18/10+6/20, Q345B strong metal frame |
| Floor Thickness(mm) | 8mm, Manganese plate or as customized |
| Side wall thickness(mm) | 6mm, Manganese plate or as customized |
| Kingpin | JOST Brand, 2 or 3.5'' bolt-in type |
| Hydraulic system | Front lifting, Original HYVA cylinder or optional Brand hydraulic Lifting |
| Brake system | Dual lines air brake system, WABCO RE 4 relay valve, T30/30+T30 spring brake chamber, 45L air tanks |
| Electrical system |
One unit of 24V 7-pin ISO standard power interface; with brake light, turn light, reverse light, side light, reflector, fog light; one set of standard Air supply interface and control interface. |
| Suspension |
1. All four axles with leaf spring suspension |
| Axle |
1. All three are mechanical axles 2. First axle with the air lifting function, rear two axles are mechanical (Optional) 3. BPW, FUWA, 20Ton, or other optional brand axles |
| Tire |
1.12 tires with 12.00R24 tires, 12+1-piece, 1 spare tire 2. First wheel with 2 vacuum widened tires with 385/65R22.5, other 8 tires with 12.00R24 3. 12R22.5/13R22.5/325/95R24 is optional |
| Painting | Complete chassis sand blasting to clean rust, 1 coat of anti-corrosive prime, 2 layers of final paint. |
| Bucket support frame | Pivoted and foldable frame to support the bucket during tipping, the pivots will be enforced for more stable load-carrying capacity. |
| Spare tire carrier | 1 unit per chassis |
