● Category:
● Brand Name: Forklift
● Dimension (mm): 4015*1410*2155
● Operating Weight (kg): 5300
● Origin: China
| Specification | FD40 | |||||
| 1 | Characteristics | Fuel type | Diesel | |||
| 2 | Load capacity | kg | 4000 | |||
| 3 | Load center | mm | 500 | |||
| 4 | Lift height | mm | 3000 | |||
| 5 | Full free lift height | mm | 135 | |||
| 6 | Fork dimension | mm | 1070×150×50 | |||
| 7 | Mast tilting angle | Front/Rear | Deg. | 6/12 | ||
| 8 | Min. turning radius | mm | 2800 | |||
| 9 | Min. width of right angle stacking channel |
mm | 4400 | |||
| 10 | Min. width of right angle channel |
mm | 2685 | |||
| 11 | Groud clearance | mm | 120 | |||
| 12 | Overhead guard height | mm | 2090 | |||
| 13 | Front overhang | mm | 500 | |||
| 14 | Performance | Max. travel speed | Full load | km/h | 18.5 | |
| 15 | Max. lift speed | Full load | mm/s | 420 | ||
| 16 | Max. traction power | Full load | KN | 20 | ||
| 17 | Max. gradeability | % | 20 | |||
| Dimensions | Total length | With fork | mm | 4105 | ||
| 18 | Total length | Without fork | mm | 3035 | ||
| 19 | Total width | mm | 1410 | |||
| 20 | Mast extended height | mm | 4270 | |||
| 21 | Mast lowered height | mm | 2155 | |||
| 22 | Chassis | Tyres | Front | 250-15-160PR | ||
| 23 | Rear | 7.00-12-12PR | ||||
| 24 | Wheelbase | mm | 1900 | |||
| 25 | Tread | Front/Rear | mm | 1160/1065 | ||
| 26 | Service weight | Kg | 5300 | |||
| 27 | Drive | Battery | V/Ah | 12/100 | ||
| 28 | Motor | Model | xinchai engine | |||
| 29 | Rated output | kw/r.p.m | 45/2450 | |||
| 30 | Rated torque | N.m/r.p.m | 184.7/2450 | |||
| 31 | Cylinders | 4 | ||||
| 32 | Displacement | L | 3.06 | |||
| 33 | Fuel tank capacity | L | 80 | |||
