● Category:
● Brand Name: Forklift
● Dimension (mm): 2730*1225*2115mm(without fork)
● Operating Weight (kg): 4300
● Origin: China
| The specification of 3 ton LPG & Gasoline forklift | |||
| Power Type | LPG & Gasoline | ||
| Rated capacity | kg | 3000 | |
| Load center | mm | 500 | |
| Lift Height | mm | 3000 | |
| Fork size | Fork size | mm | 1070×125×45 |
| Mast Tilt Angle | F/R | Deg | 6°/12° |
| Front Overhang (Wheel center to fork face) | mm | 480 | |
| Ground Clearance(Bottom of mast) | mm | 140 | |
| Overall Dimension | Length to face of fork(Without fork) | mm | 2730 |
| Overall Width | mm | 1225 | |
| Mast Lowered Height | mm | 2115 | |
| Mast Extended Height(With backrest) | mm | 4150 | |
| Overhead Guard Height | mm | 2090 | |
| Turning Radius (outside) | mm | 2440 | |
| Speed | Travel (Empty load) | km/h | 20 |
| Lifting (Full load) | mm/s | 510 | |
| Max.Gradeability (No load/Full load) | % | 20 | |
| Tire | Front | mm | 28×9-15-12PR |
| Rear | mm | 6.50-10-10PR | |
| Wheelbase | mm | 1700 | |
| Service weight | kg | 4300 | |
| Battery | Voltage/Capacity | V/Ah | 12/80 |
| Engine | Model | K25 | |
| Manufacture | GCT (NISSAN) | ||
| Rated output/r.p.m | kw | 35.6/2100 | |
| Rated torque/r.p.m | N.m | 176.5/1600 | |
| Number of cylinders | 4 | ||
| Bore×Stroke | mm | 89×100 | |
| Displacement | cc | 2488 | |
| Fuel tank capacity | L | 60 | |
| Transmission | Type | Hydraulic | |
| Stage (FWD/RVS) | 1/1 | ||
