Rated load lifting capacity

3000 KG

Center distance of rated load

500 mm

Standard mounting height

3000 mm

Door frame inclination (front/back)

6/12 º

Max. running speed (full load/no load)

20 Km/h

Lifting height

2.2 m

Max. climb (full load)

20%

Min. outside turning radius

2510 mm

Max. braking distance

2.5m

Overall dimension length (up to the fork back)

3757 mm

The width of the shape

1226 mm

Overall height (up to roof guard)

2125 mm

Total Weight

4220 KG
