● Category:
● Brand Name: Farm Tractor
● Dimension (mm): 4100*1810*2660
● Operating Weight (kg): 2825
● Origin: China
| Model | TH804 | TH904 | TH900 | TH1004 | ||
| Tractor power | 80hp | 90hp | 90hp | 100hp | ||
| Type | 4X4wheel drive | 4X4wheel drive | 4X2wheel drive | 4X4wheel drive | ||
| Overall dimension | Length (mm) | 4100 | 4100 | 4100 | 4100 | |
| Width (mm) | 1810 | 1810 | 1810 | 1810 | ||
| Height(mm) | 2660 | 2660 | 2660 | 2660 | ||
| Tread | Front tyre | 1180, 1280, 1380 | 1180, 1280, 1380 | 1180, 1280, 1380 | 1180, 1280, 1380 | |
| rear type | 1300-1430 | 1300-1430 | 1300-1430 | 1300-1430 | ||
| wheel base (mm) | 2072 | 2072 | 2072 | 2072 | ||
| Min ground clearance(mm) | 390 | 390 | 390 | 390 | ||
| Min service weight (kg) | 2825 | 2825 | 2825 | 2825 | ||
| Engine | Model/Make | Laidong | Laidong | Laidong | Laidong | |
| Type | inline, water cooled, four stroke | inline, water cooled, four stroke | inline, water cooled, four stroke | inline, water cooled, four stroke | ||
| Rated power | 58.8kw | 66.2kw | 66.2kw | 73.5KW | ||
| Fuel | diesel | diesel | diesel | diesel | ||
| Tyre | Front tyre | 8.3-24 | 8.3-24 | 6.5-20 | 8.3-24 | |
| rear tyre | 14.9-30 | 14.9-30 | 14.9-30 | 14.9-30 | ||
| clutch | dry type,single disc, double stage | dry type,single disc, double stage | dry type,single disc, double stage | dry type,single disc, double stage | ||
| steering | hydraulic steering | hydraulic steering | hydraulic steering | hydraulic steering | ||
| transmission | 4 x3 x(1+1) | 4 x3 x(1+1) | 4 x3 x(1+1) | 4 x3 x(1+1) | ||
| Suspension type | Rear positioned suspension three point linkage catagoery I or II | Rear positioned suspension three point linkage catagoery I or II | Rear positioned suspension three point linkage catagoery I or II | Rear positioned suspension three point linkage catagoery I or II | ||
| PTO | speed | 540/1000 or 540/760 | 540/1000 or 540/760 | 540/1000 or 540/760 | 540/1000 or 540/760 | |
| Size | Φ38 | Φ38,35 | Φ38, 35 | Φ38 | ||
