Product classification
Product classification
● Category:
● Brand Name: Farm Tractor
● Dimension (mm): 4920×2210×3030
● Operating Weight (kg): 4500
● Origin: China
| Tractor parameters | Product Model | HWH1404-C | ||
| Type | 4WD ( 4 x 4 wheeled drive) | |||
| Overall Dimensions (mm) | 4920×2210×3030 | |||
| Total Weight (kg) | 4500 | |||
| Min. Ground Clearance (mm) | 490 | |||
| Clutch Type | Double-acting, Dry type | |||
| Transmission box | 16+8 (Optional: 24+8) | |||
| Steering | Full hydraulic steering | |||
| Hydraulic Lifting System Type | Strong pressure double oil cylinder | |||
| Rear suspension | Enhanced | |||
| Lifting rod | Enhanced | |||
| Max. Lift Capacity (KN) | >=24.7 | |||
| Traction (KN) | >=33.1 | |||
| Wheels | Wheel Base (mm) | 2550 | ||
| Tyre Size | 14.9-28/ 18.4-38 | |||
| Front wheel tread(mm) | / | |||
| Rear wheel tread(mm) | stepless adjustable | |||
| Engine | Engine Brand | Optional (Changchai, Quanchai, Yuchai, LaiDong, Dongfanghong, Weichai, Xichai, Sida) | ||
| Engine Model | TDCI | |||
| Engine Emission Standard | According to Customers | |||
| Engine Rated Power (KW) | 102.9 | |||
| Engine Rated Speed (r/min) | 2200 | |||
| Power Output Speed (r/min) | 760/850 | |||
| Certifications | ISO 14001, ISO 45001, ISO 9001, CE | |||
